Arduino UNO WiFi Rev2.0 Dev Board

Latest Arduino UNO WiFi (Rev2.0) from Arduino.cc

Add this board to a device and you'll be able to connect it to a WiFi network, using its secure ECC608 crypto chip accelerator. The Arduino Uno WiFi is functionally the same as the Arduino UNO Rev3, but with the addition of WiFi/Bluetooth and some other enhancements. It incorporates a brand new 8-bit microprocessor from Microchip and has an onboard IMU (Inertial Measurement Unit).

Features:

• Arduino UNO Wi-Fi development board with ATMEGA4809 8-bit microprocessor
• Same as Arduino Uno Rev3 with the addition of Wi-Fi and some other enhancements
• On-board IMU (Inertial Measurement Unit)
• Secure ECC608 crypto chip accelerator
• Self-contained SoC with integrated TCP/IP protocol stack
• USB connection, a power jack, and an ICSP header
• Powered by AC adapter or battery

Specifications:

• Microcontroller: ATMEGA4809
• Operating Voltage: 5V
• Input Voltage (recommended): 7 - 12V
• Digital I/O Pins: 14 - 5 Provide PWM Output
• PWM Digital I/O Pins: 5
• Analog Input Pins: 6
• DC Current per I/O Pin: 20 mA
• DC Current for 3.3V Pin: 50 mA
• Flash Memory: 48 KB (ATMEGA4809)
• SRAM: 6,144 Bytes (ATMEGA4809)
• EEPROM: 256 Bytes (ATMEGA4809)
• Clock Speed: 16 MHz
• LED_BUILTIN: 25
• Length: 68.6 mm
• Width: 53.4 mm
• Weight: 25 g

Resources:

• Schematic
• Eagle Files
• Full Pinout diagram (pdf)
• Getting Started Guide

Packing List:

• 1 x Arduino UNO WiFi Rev2.0 Dev Board
